Technical Data - Ansmann Rm7.0 Originalbetriebsanleitung

Briefly press the battery's capacity indicator button to disable emergency
mode (all LEDs go off).
During emergency mode, you do not have access to the battery capacity. To
read out the remaining capacity of the battery despite this, briefly disable
emergency mode and briefly press the button again to have the capacity
indicated by the LEDs.

14. TECHNICAL DATA

MOTOR
Voltage
Current
Output
Control system
Torque
Weight
BATTERY
Model
Capacity
Cells
Weight
Brushless DC motor (direct drive)
36volts
max. 17A
250watts (continuous rated power)
700watts (peak output)
Motor support in 5 levels up to max. 25km/h
Energy recovery in 3 levels up to max. 8A
Pushing aid up to max. 6km/h (optional)
up to 40Nm
approx. 4.1kg
Lithium-Ion battery pack
10INR18/65-5
13Ah (468Wh) oder 16Ah (576Wh)
Type 18650, 50 cells (10S5P)
approx. 3.2kg
www.ansmann.de
43
