ORIGINAL OPERATING INSTRUCTIONS RM7.0 - ELECTRIC DRIVE FOR PEDELECS
T1 = ON / OFF drive completely
T2 = ON / OFF bicycle lighting (optional)
T3 = Display switch (total kilometres, travel time, date, time,
average speed, power, trip meter)
T4 = Assist level / energy recovery switch
T5 = Pushing aid (optional)
T6 = Assist level / energy recovery switch
range
travel time, date,
clock, average
speed,
power, trip,
total kilometres

11.2 SETTING THE WHEEL CIRCUMFERENCE

When the system is switched off (display is off), you can set the wheel
circumference (in millimetres) by simultaneously pressing buttons (T1) and
(T2) on the display (> 2 sec.). The initial value for first use is 2100 mm. By
pressing buttons (T4) and (T6) on the control unit, you can adjust the wheel
circumference in accordance with the wheel size used (roll the wheel one
revolution and measure this distance with a measuring tape).
38
T4
T1
T5
T6
T2
T3
actual speed
assist level /
energy recovery
light
indicator
battery capacity and
charging indicator
