ORIGINAL OPERATING INSTRUCTIONS RM7.0 - ELECTRIC DRIVE FOR PEDELECS
force on the bicycle (ECO = weakest braking force, HIGH = strongest braking
force). This braking force charges the battery. The energy recovery is also
indicated by the filling battery icon below the configured level.
If the battery is fully charged, none of the configured energy
recovery levels can be used and the wheel cannot be braked by
the motor.

13. EMERGENCY MODE

Basically, the drive can be controlled correctly only using the control unit
and the display. If the display is lost or in the event of a malfunction of the
display/control unit, conventional control of the drive is not possible. You can
also remove the display from the cradle (theft deterrence) and thus prevent
the drive from working.
However, the drive is also equipped with an emergency mode that allows
additional motor assist to be configured even without a display. To enable
emergency mode, press and hold the button on the battery capacity indica-
tor (> 15 sec.) until the third LED lights up. Then release the button. All LEDs
on that indicator then illuminate continuously, signalling emergency mode. In
emergency mode, the ‚NORMAL' motor assist level is set, and you can continue
riding with moderate motor support.
Do not place the display onto the cradle when emergency mode
is set. Note that quite aside from the drive, you should secure
your bike against theft when leaving it unsupervised.
42
