Place the legs (A) on the struts (B) and screw the
legs with the nuts (S2).
Place the mounting plate (E) on the fire bowl (D)
and fasten the mounting plate from above with
the screws (S1) and from below with the nuts (S2).
Then place the fire bowl inside.
1
3
Place the frame and fasten it with the nuts (S2).
Insert the grate (H). Attach the handle to the spark
guard by screwing a nut (S2) against it from below.
2
4
EN
13
