Mount the Camera

Drill holes in accordance with a mounting hole
template and screw the security mount into the wall.
If you are mounting the camera on any hard surface,
insert plastic anchors into the holes first.
1
2
3
Screw the antenna to the
Loose the adjusting knob
camera and then install
on the mount and adjust
the camera to the security
the camera to the proper
mount.
direction.
7
English
4
Stiffen the adjustment knob to
lock the camera.
Attach the Camera to a Tree
1
2
Thread the provided strap
Attach the plate to the security
to the mounting plate.
mount with the smaller screws.
Install the camera and adjust the
camera angles as instructed in step
3 in the previous installation guide.
4
3
Fasten the security mount to
a tree.
English
8
