Installation Guide
• Install the camera 2-3 meters (7-10 ft) above
the ground. This height maximizes the
detection range of the PIR motion sensor.
• For better motion detection performance,
please install the camera angularly.
NOTE: If a moving object approaches the
PIR sensor vertically, the camera may fail
to detect motion.
5 English
A B
Mounting Height:
2-3 Meters
PIR Detection Distance:
2-7 Meters
θ

Mount the Camera

Rotate to separate parts from Drill holes in accordance with the mounting hole
the bracket. template and screw the base of the bracket onto
the wall. Next, attach the other part of the bracket
onto the base.
Fasten the camera to the bracket by turning the
screw identified in the following chart anticlockwise.
English 6
