Thank you for choosing a CSL product. Please read the following user manual care-
fully so as to get the most from the product you have purchased. Before using the
product, first check that the delivered item is complete, accurate and undamaged.
1. Scope of delivery
• PCIe expansion card, M.2
• Mounting accessories
• Screwdriver
• User manual
2. Technical data
Port
Max. SSD sizes (length)
Suitable hard drive size
Note: This housing is not compatible with M.2 SATA SSDs!
3. Initial use and installation
Take the device out of the package and remove all the packaging material. Before
using the product, first check that the delivered item is complete, accurate and
undamaged.
1. Prepare the expansion card and the accessories for assembly (the upper
housing part, the base plate, the expansion card, the silicone pad, your M.2
Key-M SSD, the thread, the mounting screws and the screwdriver).
2. Then place the expansion card on a flat, level surface.
3. Mount the Key-M M2 SSD properly on the expansion card. Make sure that
you connect it properly with the port on the expansion card.
4. Mount the copper thread to the end of the SSD and push it slightly towards
the expansion card until the copper thread touches the expansion card.
8
PCIe 16x
30mm, 42mm, 60mm, 80mm
M.2 PCIe Key-M SSD
