Quick operation guide
CONTENTS
1. Introduction.
2. Technical information.
3. Safety precautions.
4. Operation.
5. Maintenance.
6. Guarantee.
1. INTRODUCTION
Dear customer, in order to ensure a safe
and reliable operation of the HDT-8 tower-
lift please follow the instructions in this
booklet carefully. Before operating the lift,
read the instructions completely and plea-
se note the technical information contai-
ned within this manual.
All VMB products undergo very rigorous
testing, under strict conditions and they
are monitored continuously during the ma-
nufacturing process.
In order to guarantee the lifts function and
safety, only original parts from the manu-
facturer must be used. If any parts other
than those of the manufacturer are used,
or the product is modified in any way, the
user forfeits all warranty rights to claim.
VMB reserves the right to modify the pro-
duct specifications without prior notice.
The model type, production year and se-
rial number must be quoted in any queries
or orders for spare parts.
PRO LIFTS S.L.
2. TECHNICAL INFORMATION
2.1 - HDT-8 Towerlift.
2.2 - Designed to lift loads, such as trus-
sing and lighting systems, vertically, up to
different heights.
2.3 - Maximum load : 350 kg (772 lb).
2.4 - Minimum load: 25 Kg (55 lb).
2.5 - Security :
ALS (Automatic Lock System).
2.6 - Maximum height : 8.2 m (26.9').
2.7 - Folded height : 1.98 m (6.5').
2.8 - Work surface :
2.11 x 2.57 m (7' x 8.4').
2.9 - Unit weight : 232 Kg (512 lb).
2.10. - Load support:
Long reinforced forks (74.5 cm).
2.11 - Construction material : 6082-T6
alluminium for the main body, comprised
of 5 profiles and a lifting carriage. Base
and legs are made of steel profile accor-
ding to DIN 2394. Catches and pulleys of
ST-37 steel.
2.12 - Winch: 1700 Kg. maximum load
with automatic brake. Certification CE and
GS TÜV.
2.13 - Cable : Steel DIN 3060. Quality 180
2
Kg/mm twist resistant.
Cable diameter: 6 mm.
