Renusol VS+ Installationsanleitung Seite 48

Q u e r v e r w e i s A r t i k e l ü b e r s i c h t - N i c h t l ö s c h e n ! A n h a n g - B a u t e i l e f ü r K o m b i n a t i o n s m ö g l i c h k e i t e n
B
48/54 | Renusol VS+ | 09/2020
Item No.
920159
M10
b
M10 860020
M10 920008
a
M10 860006
M12 920002
c
M12 860007
M12 860017
920136
M12
M12 920137
Item No.
M10 900187
Lm
M10 900188
M10 900189
L
M10 900190
M10 900191
Lg
M10 900192
Item No.
M10 900181
Lm
M10 900182
M10 900183
L
M10 900184
M10 900185
Lg
M10 900186
a: b: c:
160 mm 71 mm 65 mm
180 mm 81 mm 65 mm
200 mm 81 mm 65 mm
200 mm 81 mm 65 mm
250 mm 91 mm 100 mm
250 mm 91 mm 100 mm
300 mm 141 mm 100 mm
350 mm 191 mm 100 mm
400 mm 211 mm 100 mm
Lg/Lm: L
80/50 136 mm
100/50 156 mm
130/50 186 mm
150/50 206 mm
180/50 236 mm
200/50 256 mm
Lg/Lm: L
80/50 136 mm
100/50 156 mm
125/50 181 mm
150/50 206 mm
160/50 216 mm
200/50 256 mm
(Anbindung versetzt/
Offset Connection)
(Anbindung versetzt/
Offset Connection)
(Anbindung versetzt/
Offset Connection)
Klemmbereich
0 - 40 mm
20 - 60 mm
55 - 90 mm
75 - 110 mm
105-140 mm
125 - 160 mm
Klemmbereich
15 - 60 mm
35 - 80 mm
60 - 105 mm
85 - 130 mm
95 -140 mm
135 - 180 mm
