Renusol VS+ Installationsanleitung Seite 29

S t o c k s c h r a u b e n , - S o l a r b e f e s t i g e r a n b i n d u n g - H o r i z o n t a l e M o d u l A u s r i c h t u n g
1
S t o c k s c h r a u b e n , - S o l a r b e f e s t i g e r a n b i n d u n g - H o r i z o n t a l e M o d u l A u s r i c h t u n g
3
2
M10: S7
M12: S9
4
M10: SW17
M12: SW19
M10: SW17
M12: SW19
5
l2
l1
M10
l1 >40mm
l2 <40 mm
Renusol VS+ | 09/2020 | 29/54
M12
>48mm
