CABINET WITH PAYMENT-SLOT ERECTION KIT
1. Unpack the machine (01) and its cabinet (02).
2. Fit the cabinet feet (03) that you will find in the machine packing, onto the bottom of the cabinet;
adjust them so that the unit is level and balanced.
3. Connect the machine onto its cabinet as shown on the figure by setting in the four Ø 6 washers
(04) and turn-in the four screws (05) into the inside of the cabinet.
4. Unscrew all the screws (06) and remove the back lid (07).
5. On the base of the machine, in the blanking area, cut out a 55x35 cavity (08).
Important: take care that the edges of the cavity are accurately finished and that all resi-
dual fins and burrs have been removed.
6. As shown at page 2/9, by means of the spacers (10) connect the electronic board (11) onto the
electric CPU board (09).
7. Fix the transformer into the machine (12) by means of the screws (13).
For the Espresso Version, as shown in the figure at page 2/9, it is to be fixed onto the electric
panel board (14).
For the Instant Version, as shown in the figure at page 2/9, it is to be fixed onto the side of the
machine (01).
8. Connect up the wiring (15) according to the attached electrical circuit diagram (see page 4/9)
by passing through the cavity (08) previously cut out on the base of the machine and fasten the
cable to the cabinet at the given points (16).
LEGENDA Fig. 4
1 = Connection for BDV and MDB
2 = 230 VCA power supply
3 = 3-way connector
4 = 2-way connector
5 = 24 VCA power supply
6 = Transformer support
7 = Connection for Executive
1. Connect the wiring (D) as shown in the figure.
2. Fit the wiring (D) through the relative cavity (E).
3. Tie the wiring (D) up together with the clamps (F) supplied with the kit.
MOUNTING INSTRUCTIONS FOR
ENGLISH
CODICE - CODE
599545600
COMPILATO - FILLED OUT CONTROLLATO - TESTED
MOSCONI PERSONENI
FOGLIO - SHEET
6/9
DATA - DATE
28-09-2000
