Wenn der Türflügel ausgerichtet ist und alle
Dichtprofile aufgesteckt wurden kann die
Nulllage eingestellt werden. Dazu werden zunächst
die Befestigungsschrauben der Nulllage gelöst.
Dann wird der Türflügel im gewünschten Winkel
ausgerichtet und die Schrauben wechselseitig auf
das max. Anzugsmoment von 6,5 N·m wieder fest-
gezogen und nach ca. 15 Minuten nachgezogen.
Once the door wing is aligned and all
sealing profiles are fitted, the zero position
can be adjusted. Therefore loosen first the screws of
the zero position. Afterwards align the door wing to
the desired angle and tighten the screws alternately
to the maximum torque of 6,5 N . m and retighten
after approx. 15 minutes.
5
2x pro Band
2x per Hinge
max 6,5 N . m
