Wichtig: Schrauben und Dübel müssen an die
jeweilige bauliche Situation angepasst sein!
Der Bohrer ist entsprechend der Größe der Dübel
zu wählen. Die Schrauben sollten aus Edelstahl A2
oder A4 bestehen und einen Senkkopfdurchmesser
von min. 10 mm und max. 12 mm aufweisen. Bitte die
entsprechende Kopfhöhe prüfen, so dass die Schrau-
ben das Aufsetzen des Abdeckbleches 8406-2MS
zum Schluss der Duschenmontage nicht behindern.
Important: Screws and dowels must be suitable
for the corresponding structural situation! Select
a drill bit that corresponds to the size of the dowels.
The screws should be made of stainless steel 304 or
316 and provide a countersink diameter of at least 10
mm and 12 mm at most. Please check the height of
the screw heads to make sure that the screws do not in-
terfere with the 8406-2MS cover plates, which will be
fitted during the final steps of the shower installation.
2x pro Band
2x per Hinge
4
