1.0. Layout
1. Machine base
2. Pillar
3. Fixing screw
4. Drill table
5. Clamping screw
6. Machine head
7. V-belt
8. Motor
9. Grip knobs
10. Scroll chuck
11. Spindle
12. Mounting holes
13. Hinged chip guard
14. Depth stop (only NBD 401)
15. Tightening screw
16. Screw
17. Clamping screw (only NBD 501)
18. On switch
19. Off switch
20. Grub screw

2.0. Items supplied

b Pillar drill
b Ring gear drill chuck
b Drill chuck key
b Hinged chip guard
b Drill table

3.0. Proper use

This pillar drill is designed for drilling metal, plastic,
wood and similar materials. It is intended for use in
the private sector only.
Food and harmful materials may not be processed
with the machine. The drill chuck is designed solely
for the use of drill bits and tools which have the
12
29.12.2008 13:22 Uhr Seite 12
stipulated shaft diameter and for cylindrical tool
shanks. The machine is intended for use by adults
only. It is designed for temporary operation (S2 15
min). Any use of the machine other than that which is
cited in these operating instructions releases the
manufacturer from all liability and renders every
warranty claim null and void.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.

4.0. Safety information

Please refer to the booklet included in delivery for the
safety instructions.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.

5.0. Technical data

NBD 401
Nominal input voltage 230V ~/ 50 Hz
Power rating
Operating mode S2 15 min.
Motor speed 1450 min-1
Output speed 580 – 2.650 min-1
Speed levels
Drill chuck mount
Scroll chuck Ø 1.5 - 13 mm
Max. shaft diameter
Throat
Drill depth
Pillar diameter
Height
Weight
LPA sound pressure level in idle mode 62,1 dB(A)
LWA sound power level in idle mode 75,1 dB(A)
350 W
5
B 13
13 mm
104 mm
50 mm
46 mm
580 mm
18,7 kg
