Thermopatch HS-21-SQR Penguin Anleitung Seite 16

2.1 Tapping screw
2.2 Nylock nut
2.3 Collar bearing
2.4 Spring dowel
2.5 Bearing
2.6 Hinge block
2.7 Pull relief
2.8 Ring
2.9 Spring dowel
2.10 Bolt
2.11 Eccentric disc
3 x 25
M8
10170-P14
10-12-10
Ø 6 x 40
4030-P10
M8
Ø 10 x 8.5 x 60
M8 x 80
2 DIN 965
1 DIN 7971
4 SPAPEN-21012
1 DIN 7344
2 SPAPEN-21203
1 SPAPEN-21017
2 SPAPEN 02-02
1 DIN 9021
1 DIN 7346
1 DIN 933
SPAPEN-21005
16
