Network Topology

A typical network topology for the EAP is shown below.
Router
PoE Switch
EAP Controller
Management Host EAP EAP EAP
Clients
The EAP can only be powered by a PSE device, such as a PoE
switch. A DHCP server (typically a router) is required to assign
