Note: Images may differ from your actual product�

Network Topology

A typical network topology for the AP is shown below�
Internet
Router
All APs can be centrally configured and monitored via Omada Software Controller
or Omada Hardware Controller� You can get Omada Software Controller from our
website https://www.tp-link.com�
Hardware Installation
■ Option 1: Ceiling Mounting
Follow the steps below to install the AP with the provided accessories:
Note: The mounting bracket and the accessories (quantity and size) may vary by product�
Washers
1
Remove the ceiling tile�
Switch
Software Controller
Pan-head Screws
AP
AP
AP
Or
Hardware Controller
Wing Nuts

English

Clients
5
