Character
Unit of measure-
ment, international
U
V
1
U
V
2
P
W
1
f
Hz
I
mA
max
C
Ah
T
°C/ °F
m, s, kg, A, mm, V,
W, Hz, N, °C, dB,
min, m/s
Operating Instructions.
Connect the battery charger to the socket outlet without
a battery inserted. The yellow LED indicator lights up and
signals operational readiness.
Insert the battery.
The monitoring of the charge procedure is signalled by a
flashing green light.
The end of the charge procedure is indicated by continu-
ous green lighting.
Meaning of the LED indicator.
LED indicator
continuous yellow
light
green flashing light The rapid charging is active.
continuous green
light
red flashing light
green flashing light
and red flashing
light
Unit of measure-
ment, national
V
V
W
Hz
mA
Ah
°C/ °F
m, s, kg, A, mm, V,
W, Hz, N, °C, dB,
2
2
min, m/s
The rapid charging starts automatically as soon as the bat-
tery temperature is within the charge-temperature range
of 5 °C to 45 °C.
In case of an extremely deep discharged battery, the
charging procedure may not start until after a delay of
several minutes after sliding on the battery.
When lithium-ion batteries are fully charged, the battery
charger switches off automatically.
If the battery becomes discharged within a short time
despite being charged correctly, it has reached the end of
its service life.
Meaning
The battery charger is ready for operation; mains voltage is given.
The rapid charging is completed. Trickle charging is active
(only NiCd/NiMH batteries).
Charging not possible due to the following possible reasons:
– Contacts contaminated. Improvement measure: Clean the contacts by inserting and
removing the battery several times.
– The battery is defective. Improvement measure: Replace the battery!
The battery temperature is not within the charge-temperature range of 5 °C to
+45 °C. The rapid charging procedure starts as soon as the battery reaches the
allowable charging-temperature range.
Explanation
Rated supply voltage
Rated output direct voltage
(rated battery voltage)
Power input
Frequency
Maximum rated direct output current
(max. rated charging current)
Capacity
Temperature
Basic and derived units of measurement from the
international system of units SI.
