Internal
Connectors
LED Features
Back Panel
Connectors
Continued from previous page
∙ 1x 24-pin ATX main power connector
∙ 1x 8-pin ATX 12V power connector
∙ 6x SATA 6Gb/s connectors
∙ 1x M.2 slot (M-Key)
∙ 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 5Gbps ports)
∙ 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin system fan connector
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 1x Clear CMOS jumper
1x TPM module connector
∙
∙ 1x Serial port connector
∙ 1x Tuning Controller Connector
∙ 1x 4-pin RGB LED connector (For B560M PRO & B560M
BOMBER)
∙ 1x 3-pin RAINBOW LED connector (For B560M PRO &
B560M BOMBER)
∙ 4x EZ Debug LED
∙ 1x HDMI port
∙ 1x VGA port
∙ 1x DisplayPort (For B560M PRO only)
∙ 1x PS/2 keyboard/ mouse combo port
∙ 2x USB 2.0 Type-A ports
∙ 4x USB 3.2 Gen1 5Gbps Type-A ports
∙ 1x LAN (RJ45) port
∙ 3x audio jacks
Continued on next page
5
Specifications
