RFC-4800 IO-Link Gebrauchsanleitung
RFC-4800 IO-Link User Manual
3.4 Montagehinweise
Es sind bei der Montage ausschließlich die mitgelieferten
Linsenflanschkopfschrauben zu verwenden. Bei der Montage ist
das maximale Anzugsmoment von 250 Ncm zu beachten.
Der Mindest-Biegeradius des Kabels beträgt 70mm. Ein
dauernder Zug auf das Anschlusskabel in jeglicher Richtung ist
zu vermeiden.
Wenn das Kabel im Gebrauch bewegt wird, muss das Kabel
durch geeignete Maßnahmen (Schelle o.ä.) nach dem Austritt
fixiert werden.
4. Elektrische Daten / electrical data
Versorgungsspannung / supply voltage:
24 VDC ( 18...30 VDC)
Kabel / cable:
4-polige, ungeschirmte Leitung
4-pol, unshielded cable
4. 1 Elektrische Anschlussbelegung / electrical connections
Signal / Signal
Versorgung / Supply Ub
GND
C/Q
Nicht anschliessen *
Not connected *
*) Alternativ auf GND legen / Alternatively connect to GND
P/N 403000388/00
Änderungen vorbehalten / Specifications subject to change
ACHTUNG !
Maximale Verlängerung des Kabels
nur bis Gesamtlänge 20 m
Aderfarbe / Wire color
Kabel / Cable
Code -25_- / -26_- / -27_-
braun / brown
weiss / white
gelb / yellow
grün / grün
3.4 Installation Instructions
Only the the delivered button head socket screws with flange
are to be used. Pay attention to the maximum tightening torque
of 250 Ncm when fastening.
Minimum bending radius of the cable is 70mm. Avoid steady
tension on the cable in any direction.
If the cable is moving in the application, appropriate action is to
be taken to fix the cable after the outlet of the sensor (use of
fixation clamp or similar).
Anschlussbelegung / Pin assignment
M12-Stecker / M12 connector
Code -551-
pin 1
pin 3
pin 4
pin 2
07/2015
CAUTION !
Extension of the cable only to a
maximum length of 20 m
Seite/page 3 von/of 7
