2. Buttons and functions

4
3
2
1
1. ON/OFF button
2. Rip fence
3. Upper pulley wheel cover
4. Blade tension knob
5. Upper blade wheel cover screw
6. Blade guide adjustment knob
7. Upper blade guide assembly
8. Mitre gauge
9. Table
10. Dust extraction port (× 2)
11. Lower blade pulley wheel cover screw
12. Blade tracking knob
13. Belt tension
14. Motor
15. Table trunnion
16. Pointer
17. Table locking wing nut
5
6
7
8
9
10
11
15 16
5
12
13
14
17
