6. Troubleshooting

Problem Possible cause
The machine does No power supply to the wall socket.
not start when
Faulty switch.
the on/off switch
One of the covers is open.
is pushed.
The saw blade The blade tension is loose.
does not move
The blade has come off one of
when the motor
the pulley wheels.
is on.
The saw blade has broken.
The drive belt has broken.
The saw blade The cut was done freehand.
does not cut
Feed speed too high.
straight.
The saw blade is damaged or blunt.
The blade guides are not set correctly. Adjust the blade guides.
The saw blade The saw blade is blunt.
does not cut or
cuts very slowly.
Blade fitted upside down.
Sawdust builds up This is completely normal.
inside the machine.
The saw does not The table is not correctly set in relation
cut at angles of 45° to the blade.
or 90°.
Blunt blade or too high a feed rate.
The saw blade The blade pulley wheels are not in line,
does not align bad bearings.
centrally on
The blade pulley wheels are not in line,
the blade pulleys.
incorrectly set.
Incorrect blade.

7. Waste management

Follow local ordinances when disposing of this product. If you are unsure how to proceed, contact your local authority.

8. Specifications

Voltage
Power
No-load idle speed
Blade length
Blade width
Blade speed
Table size
Sound pressure (LpA)
Sound power (LwA)
Weight
230 V AC, 50 Hz
420 W
1400 rpm
1783 mm
6–13 mm
660/960 m/min
350 × 330 mm
77.4 dB(A) K: 3 dB
90.4 dB(A) K: 3 dB
35 kg
Solution
Check fuses and cables.
Close the cover.
Turn off the motor and adjust the tension.
Open the covers and check.
Replace the saw blade.
Change drive belt.
Use a fence to guide the workpiece.
Do not apply so much pressure.
Replace the saw blade.
Change blade (6 TPI* for wood and soft
materials, 14 TPI* for hard materials)
*TPI= teeth per inch.
Fit the blade correctly.
Clean the saw regularly with a brush and
dust extractor.
Adjust the table.
Replace the blade or reduce pressure
on the workpiece.
Contact our Customer Services.
Adjust the alignment using the knob on
the back of the saw.
Change blade.
