7. Operating elements

a) Air purifier

2
3
10
1 Control panel / LED display
2 Air outlet
3 Housing
4 Air intake
20
1
4
5 Sensor
6 Sensor cover
7 Safety trigger
8 Filter cover
4 9
9 Air filter
10 Power cord
5
6
7
8
