TELECO AUTOMATION TVRGBD000ST24 Bedienungsanleitung

IT - DISPOSITIVO SLAVE PER IL CONTROLLO DI STRIP LED ANODO COMUNE
EN - SLAVE DEVICE CONTROLLING LED STRIPS COMMON ANODE
FR - DISPOSITIF ESCLAVE POUR LE CONTROLE DES LEDS AVEC ANODE COMMUNE
DE - SLAVE-GERÄT ZUR ANSTEUERUNG VON LED STRIPES – GEMEINSAME ANODE
IT - Codice prodotto
FR - Code du produit
-
12-24
+
Vdc
12-24Vdc
IN
1
2
3
4
12-24Vdc OUT
-
+
12-24Vdc
IN
1
+ -
2
3
4
12-24Vdc OUT
SLAVE IN
SLAVE OUT
IT - Attenzione: l'alimentazione fornita al dispositivo deve corrispondere al voltaggio del carico!
EN - Attention: the power supply connected to the device must correspond to the voltage of the load!
FR - Attention: l'alimentation fournie au dispositif doit correspondre à la tension de la charge!
DE - Achtung: Die Stromversorgung des Geräts muss mit der Spannung der Last übereinstimmen!
IT - Montaggio
TVRGBD000ST24
TELECO AUTOMATION SRL -
++39.0438.388511 FAX: ++39.0438.388536 - www.telecoautomation.com
TELEPHONE:
This document is the property of Teleco Automation Srl who reserves all reproduction and copying rights
EN - Product code
DE - Artikelnummer
LINE L
IN
N
TVRGBD000ST24
EN - Mounting
165 mm
IT - Fori di fissaggio
EN - Fixing holes
FR - Trous de fixation
DE - Befestigungslöcher
Via dell'Artigianato, 16 - 31014 Colle Umberto (TV) ITALY
TVRGBD000ST24
IT - Attenzione: non invertire la polarità dei led!
EN - Attention: do not invert the polarity of the led!
FR - Attention: ne pas inverser la polarité des leds!
DE - Achtung: Polung der LEDs nicht invertieren!
MASTER
SLAVE OUT
(max. 5 slaves)
FR - Fixation
47 mm
Slave 3x4A
+
9
10
11
12
13
-
14
+
9
10
11
12
13
-
14
DE - Montage
T312.04
DOC.:
COM +
COM +
COM +
R (L3) -
G (L2) -
B (L1) -
COM +
COM +
COM +
R (L3) -
G (L2) -
B (L1) -
40 mm
06/02/15
DATE:
