Remote Control - LaserLiner Cubus Bedienungsanleitung

Control panel Cubus
3 4
2
1
slope
1 auto/slope function
2 auto/slope function LED:
LED off: automatic alignment
LED on: manual alignment
3 ON/OFF button
4 Operation indicator
(LowBat: LED flashes)
5 Tilt function LED
6
Tilt function
7 Infrared signal receptor
18
EN
Cubus

Remote control

10
5
6
13
7
8 Infrared signal emitter
9 Operation indicator
10
Rotary speed for selection
600 / 330 / 30 / 0 rpm
11
Scan mode
10° / 45° / 90° / 180°
12
Positioning button
(rotate to the right)
13
Positioning button
(rotate to the left)
8
9
11
12
1
