• Installation on concrete slab compulsory and necessary for warranty to be valid. Thickness: 20 cm minimum. Ensure that slab is completely
smooth and level.
• Swimming pool should be oriented so that skimmer inlet(s) face(s) prevailing wind, in order to optimise surface particle filtration.
SUMMARY:
- Erecting the sides of the pool
- Positioning the supports and the brackets
- Preparing the sides of the pool
- Installing the felt underlay and the liner
- C utting the liner, fitting the backwash inlet
nozzle and the skimmer
- Installing pine coping
- The ladders
- Installing the automatic pool cleaner
2a - P osition the horizontal reinforcements level with the upper edge on the exterior of the structure. Make level and screw together from the pool interior, until screw heads
to not protrude.
2b - Pre-drill 3 holes of 6 mm (on the corners).
2c - Widen the holes to a depth of 45 mm using a flat 12 mm drill bit and screw in using three 6x90 screws.
2d - Pre-drill three 6 mm holes and screw into the corners.
2e - Put the brackets in place taking account of the top-bottom direction, mark in their position, drill them and screw them in until the screw heads are fully embedded in the wood.
2f - Screw in the horizontal reinforcement with the consoles.
3a - Screw the mouth of the skimmer into the upper plank using two (2) round-headed screws which you will find in the bag of screws supplied in the skimmer box.
3b - Install the square skimmer outer seal as well as the skimmer body.
3c - Secure the assembly using the eight (8) round-headed screws taken from the packet of screws provided in the skimmer box, tightening efficiently to ensure good leaktightness.
(Screw by hand)
3d - Position one of the skimmer seals.
3e - Drill the tracks according to the measurements (3 cm from the ends and then approximately every 20 cm).
3f - Screw in the first length of track for the liner using 4x40 stainless steel screws.
3g - At the corners, partially cut a "V" in the track in order to bend the profile. Screw at a distance of 3cm either side of the corner, then screw all of the tracks.
4a - Put the ground in place.
4b - Cut out the felt underlay using a Stanley knife or a pair of scissors.
4c - Install the liner when the outdoor temperature is between 20°C and 25°C.
4d - Fit the corners of the liner into the corners of the pool.
4e - Hook the liner on to the lip of the track.
4f - Stretch the liner to its full extent.
4g - Fill the pool with water to a depth of 2 cm.
4h - Smooth out the creases and fill with water up to 5cm below the backwash inlet nozzle.
5a - Continue to fill with water up to 5cm under the backwash inlet nozzle.
5b - Position the backwash inlet nozzle from inside the pool.
5c - Cut a hole in the liner at the level of the nozzle, leaving approx. 2mm clearance. Put the joint and the delivery nozzle in place.
5d - Tighten the outer nut on the nozzle well enough to ensure it is fully leaktight, following the tip shown in the diagram, if necessary.
5e - Bind the threaded section of the nozzles with Teflon tape in the anti-clockwise direction.
5f - After binding the threaded section with Teflon, screw the threaded shut-off valve into the body of the skimmer. Close the valve.
5g – Install one of the 4-meter pipes and secure using a metal collar, then fill with water up to 5cm below the skimmer.
5h – Put in the skimmer seal and the frame.
5i – Screw the whole skimmer using 18 flat-headed screws from the bag of screws which you will find supplied in the skimmer box
5j – Cut out the liner on the inside of the skimmer frame.
5k –The water is at the correct level when it is halfway up the skimmer.
the coping is a trimming element. You must not walk, run or sit on it. Not covered by the warranty: changes in colour, distortions
(splits, crevices, cracks, knots or splinters) occurring naturally or as the result of incorrect installation.
6a - Pre-drill the inner copings every 70cm approximately and screw leaving a gap of 5 to 8mm between them. Start at least 3cm from the ends.
6b - Pre-drill the outer coping.
6c - Screw down the outer coping.
7
The ladders must not be used for other purposes. The maximum permissible load is 150 kg.
The entry ladder must be placed in a safe position, if it is not used.
7a - Put the ladder in position. To do that, expel the air from the steps if necessary.
7b - Mark in the position of the ladder sockets.
7c - Drill the coping and the support under the coping using a hole cutter (not supplied) in order to insert the sockets.
7d - Place the ladder socket into the hole and fix in place using two 6x60 hinge screws.
7e - Position the wooden ladder against the horizontal support under the coping.
7f - Mark in the position of the holes and drill.
7g - Check the positioning of holes and drill the sides of the wooden ladder so that you can lock the bolt supplied into place.
NOTICE 300x555 - H140-2018/1.indd 18
Before you start assembling the pool, check through the list provided on page 5
(warranty) to make quite sure that you have all the necessary parts.
1a - Insert the posts into the metal plinths
1b - Put the bottom row of planks into position.
1c - H old these planks in place using upright metal plates (at right angles). Secure with 12x160 japy bolts at the bottom but do
not tighten up.
1d - P lace a standard length temporary plank along each edge of the pool basin. Secure using 12x120 japy bolts. Tighten up all the
bolts (top and bottom).
1e - To imperatively check alignment of wedges (chalk line) and diagonals (10 m ribbon); A = B
1f - 1 st case scenario: the plinth does not obstruct the drill:
Drill the central hole (8 mm in diameter), drive in the anchoring pins and tighten up.
1g - Drill the remaining holes (20 mm in diameter), drive in the anchoring pins and tighten up. Repeat the process on each plinth.
1h - 2 nd case scenario: the plinth is obstructing the drill:
Mark in the position of the holes with paint or felt tip pen.
1i - R emove the post and its plinth, drill the holes, reposition, drive in the anchoring pins and tighten. Repeat the process on each plinth.
- Installation of angle junction in reinforced steel
- Installation of angle junction
1j - U nscrew the upper and lower Japy bolts and let the provisional upper planks descend. Interlock the planks using the sacrifice
piece provided for this purpose. If the tongues, which correctly align the planks when they are interlocked, are missing or
have minor flaws, this does not in any way affect the mechanical strength of the wood, its durability or the assembling of the
pool.
1k - Put the japy bolts in place.
1l - Position the plank for the backwash inlet on the 8th row opposite the skimmer.
1m - Position the 2 remaining standard length planks and the upper planks along the edge of the pool.
1n - Check the alignment of the lower and upper skimmer planks.
1o - Tighten up all the japy bolts (see fig. J for the plinths and fig. K for the upper part of the post).
1p - Do the preparation for drilling the upper planks, taking account of the measurements.
1q – Nail the finishing strips to the posts.
17
