EX-6006PoE
3. Layout, Connections & LED's

3.1 Layout

+12V Connector
for included external
Power Supply
3.2 Connections & LED's
+12V T-Block:
GND (Ground)
+12V
+12V Connector:
© Copyright 2020 by EXSYS Vertriebs GmbH. All Rights Reserved
Power LED
+12V T-Block
for optional external
Power Supply
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
ATTENTION!!!
Use only with Power Supply which is included in delivery!
PoE LED
RJ45 Port for
Data Input
9
English
No Function
RJ45 Port for
PoE Output
