Item Designation
no.
8 Blue LED
9 Start button
10 Charge level indicator Shows the capacity of the rechargeable battery.
11 Warning note sticker
12 Rechargeable battery
13 Release button
14 Compatibility mark
Radio interface
15
symbol
16 Specification plate
1)
The Bluetooth® brand and its logos are the property of Bluetooth SIG, Inc. and are used
under license by Geberit.
Radio interface function
The pressing tools with the type designation "plus" are equipped with a Bluetooth® radio
interface. When used together with a mobile end device (iOS or Android) and the NovoCheck-
App (www.novopress.de), the following functions are available:
• reading out data, such as the number of pressing operations, tool status, serial number
• checking the tool electronics
• setting the pressing point light and the time until the idle state
• creating construction site reports
To establish a connection between the pressing tool and an end device, the pressing tool must
be ready for operation (tap the start button, green LED lights up, blue LED flashes) and the
NovoCheck-App must be installed on the end device. The blue LED lights up when the
Bluetooth® connection is successfully established.
The blue LED goes out if it was not possible to establish a connection to the end device before
the first pressing operation. The pressing tool must be completely switched off and on again
before establishing a connection can be reattempted. The rechargeable battery must also be
removed briefly.
18014400405810571-1 © 12-2018
968.403.00.0 (00)
Function/description
• Lights up: radio communication is active.
• Flashes: radio communication can be established.
• Briefly press the button: activates the tool from idle state.
• Long press (> 2 sec.): starts the pressing procedure.
• Warning sign: hazard from flying fragments.
• Safety note: read the operating instructions before
commissioning and using the tool.
Only use Geberit lithium-ion batteries of type
Milwaukee 12 V.
Push in both release buttons: rechargeable battery can be
pulled out.
Pressing attachments with the symbol
with the pressing tool.
1)
Bluetooth® radio interface
–
EN
are compatible
