EDS 3000 IO-Link
9.2

SETTING RANGES FOR THE SWITCHING OUTPUTS

Measuring range Untere Grenze
von RP / FL
in bar in bar
- 1 .. 1 -0.98
0 .. 1 0.010
0 .. 2.5 0.025
0 .. 6 0.06
0 .. 10 0.10
0 .. 16 0.20
0 .. 40 0.4
0 .. 100 1.0
0 .. 250 2.5
0 .. 400 4
0 .. 600 6
* All ranges shown in the table can be adjusted by the increments shown.
9.3

ANALOGUE OUTPUT

The universal output "ou2" can be set to 4..20 mA or 0..10 V (corresponding to measuring
range).
Edition: 2014-11-06
Upper limit of Minimum
SP / FH difference betw.
RP and SP
or FL and FH
in bar
1.00 0.02
1.00 0.010
2.50 0.025
6.00 0.06
10.00 0.10
16.00 0.20
40.0 0.4
100.0 1.0
250.0 2.5
400 4
600 6
HYDAC ELECTRONIC GMBH
11
Increment*
in bar
0.01
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
1
Part No.: 669897 E
