2.1.2 System Health Monitor Functions
2.1.3 Intelligence
Downloaded from www.Manualslib.com
I/O Connectors
• One connector for 2 additional external USB 2.0/1.1 ports
• Three connectors for 3 external IEEE 1394a ports (AD77
INFINITY only)
• One connector for 1 external game/MIDI port
• One connector for external line-out and mic-in jacks
• Two internal audio connectors (AUX-in and CD-in)
• One 4-channel audio output connector
• One S/PDIF-in/out connector
• One connector for IrDA interface
• One RAID IDE connector (AD77 INFINITY only)
• One connector for serial ATA interface (AD77 INFINITY only)
• Two IDE connectors
• One floppy drive interface supports up to two 2.88MB floppy
drives
• One ATX power supply connector
• One Wake-On-LAN connector
• One Wake-On-Ring connector
• CPU, chassis and second chassis fan connectors
The system board is capable of monitoring the following "system
health" conditions.
• Monitors CPU/system temperature
• Monitors ±12V/±5V/3.3V/CPU/VBAT(V)/5VSB(V) voltages
• Monitors CPU/chassis fan speed
• Automatic chassis fan on/off control
• Read back capability that displays temperature, voltage and fan
speed
CPU Temperature Protection
The CPU Temperature Protection function has the capability of
monitoring the CPU's temperature during system boot-up. Once it
has detected that the CPU's temperature exceeded the CPU
temperature limit defined in the BIOS, the system will automatically
power-off after 5 warning beeps.
