1.4.11 IEEE 1394a Connectors (AD77 INFINITY only)
18
Downloaded from www.Manualslib.com
1 TPA+ 2 TPA-
3 Ground 4 Ground
5 TPB+ 6 TPB-
7 VCC 8 VCC
9 Key 10 Shield
manuals search engine
9 1
2
10
9 1
10 2
10
2
1 9
9 1
J15
2
10
9 1
J14
2
10
2
10
J8
1
1394a (J8, J14, J15)
