Expansion Slots
The system board is equipped with 1 AGP slot, 5 PCI slots (1
shared with CNR slot) and 1 CNR slot.
AGP is an interface designed to support high performance 3D
graphics cards. It utilizes a dedicated pipeline to access system
memory for texturing, z-buffering and alpha blending. The AGP slot
supports AGP 8x with up to 2132MB/sec. bandwidth and AGP 4x
with up to 1066MB/sec. bandwidth for 3D graphics applications.
AGP in this system board will deliver faster and better graphics to
your PC.
The CNR slot supports modem riser card only.
Onboard Audio Features
- AC'97 2.2 S/PDIF extension compliant codec
- Supports Microsoft
- AC'97 supported with full duplex, independent sample rate
converter for audio recording and playback
- 6-channel audio output
Onboard LAN Features (AD77 INFINITY only)
- Uses VIA VT6103 Phy chip
- Integrated IEEE 802.3, 10BASE-T and 100BASE-TX compatible
PHY
- VIA 8235 MI (Management Interface)
- Integrated power management functions
- Full duplex support at both 10 and 100 Mbps
- Supports IEEE 802.3u auto-negotiation
- Supports wire for management
ATA RAID - Redundant Array of Inexpensive Disk
INFINITY only)
- RAID 0 (striping) or RAID 1 (mirroring)
- One independent IDE channel supports 2 hard disk drives
(UDMA modes 33/66/100/133 or EIDE)
- Suppor ts PIO modes 0/1/2/3/4, DMA modes 0/1/2 and
UDMA modes 0/1/2/3/4/5/6
manuals search engine
®
DirectSound/DirectSound 3D
(AD77
