SmartRelais 2
1. Attach the base plate of the SmartRelay 2 to the desired location
2. Connect all additional components.
3. Feed the power supply cable through the recess provided for this
IMPORTANT
Danger of short circuit due to missing seal
The cable entry of the WP version of the SmartRelay 2 is not sealed.
Water can enter.

4. Connect the power supply.
5. Actuate an identification medium to test the function.
9

6 Signalling

Signalling
Constantly (blue)
1 x briefly (red)
EN
(you can use the base plate as a drilling template).
purpose.
Seal the cable entry yourself with a suitable sealant (e.g. vinegar-
free cross-linking silicone).
Assembly completed.
Meaning
Identification medium accepted, relay con-
tacts are currently connected
Identification medium not authorised
6. Signalling
27 / 112
