ENGLISH
GENERAL
Carefully read the following important information regarding installa-
tion safety and maintenance. Keep this information booklet accessible
for further consultations.
The appliance has been designed as a exhausting version (external
exhaust).
SAFETY PRECAUTION
1. Take care when the cooker hood is operating simultaneously with an
open fireplace or burner that depends on the air in the environment and
which is supplied by other than electrical energy, as the cooker hood
removes the air from the environment which a burner or fireplace need
for combustion.The negative pressure in the environment must not
exceed 4 Pa (4 x 10 -5 bar). Provide adequate ventilation in the envi-
ronment for a safe operation of the cooker hood.Follow the local laws
applicable for external air evacuation.
2. WARNING!!
In certain circumstances electrical appliances may be a danger
hazard.
A) Do not check the status of the filters while the cooker hood
is operating
B) Do not touch the light bulbs after appliance use
C) Flambè cooking is prohibited underneath the cooker hood
D) Avoid free flame, as it is damaging for the filters and a fire
hazard
E) Constantly check food frying to avoid that the overheated oil
may become a fire hazard
F) Disconnect the electrical plug prior to any maintenance.
INSTALLATION INSTRUCTIONS
• Electric Connection
The appliance has been manufactured as a class II, therefore no earth
cable is necessary.
The appliance is specifically designed for combination with a central
mechanical ventilation system, for home use.
The cookerhood is supplied with electrical power by connecting it to
the motor of the central exhausting system.
The electronics inside the cookerhood will cause it to send a phase
back to the motor of the central exhausting system when the hood is
opened, which is used to switch the motor into high speed.
The electrical diagram that indicates how the connections should be
made is shown in (fig. 5).
Important: it is necessary to install the hood in such a way that the
electrical connection between the cookerhood and the motor of the
central exhausting system can be disconnected at all times. The con-
nection plug must be reachable.
• The appliance must be installed at a minimum height of 700 mm from
an cooker stove in case of a gashob or an electrical hob.
If a connection tube composed of two parts is used, the upper part must
be placed outside the lower part.
Do not connect the cooker hood exhaust to the same conductor used
to circulate hot air or for evacuating fumes from other appliances gen-
erated by other than an electrical source.
• ATTENTION: should the lamps not work, make sure they are well
tightened.
• MOUNTING OF THE HOOD BETWEEN TWO HANGING CUP-
BOARDS
Drill 2 holes of 2,5 mm diameter on the side of the hanging cupboards
as shown in (fig. 1) considering also the thickness of the front panel, so
that the hood remains at the same level of the side hanging cupboards.
Fix the hood to the hanging cupboards through 4 screws, which are
ENGLISH
appropriate to that kind of cupboard.
Close the space, which eventually remains between the hood and the
wall adjusting the spacer (L) by acting on the appropriate screws (P)
(fig. 1).
• MOUNTING OF THE HOOD ON THE WALL
Drill 6 holes on the wall as shown in (fig. 2).
Fix the spacer (L) on the wall at the right height, according to the depth
of the hanging cupboards (fig. 2).
Adjust the position of the upper clamps (M) (fig. 2), according to the
depth of the side hanging cupboards.
Fix the hood on the wall through 4 screws and dowels with expanding
plug , which are appropriate to that kind of wall (ex. concrete, plaster-
board, etc.).
Fix the hood to the spacer through the screws (P) (fig. 1).
• FIXING OF THE FRONT PANEL
Take off the door (E) by removing the grill (G) and pulling at the same
time the special spring locking knobs (H) (fig. 3).
Fix the door on the front panel through the screws at the level indicated
in (fig. 3).
Replace the door by inserting it in the upper and lower slides until the
spring locking knobs (H) are released.
• EXHAUSTING VERSION
Insert the coupling flange (B) in the hole (A) and connect the discharge
pipe to the same (fig. 1).
• CONTROL
- To switch on the hood pull out the front panel as in fig.4a.
- To switch off the hood close the front panel as in fig.4b.
When the hood is switched on the lights go on and the motor of the
central ventilation system is switched into cooking setting.
With centralised vacuum system it is necessary to follow the indications
in the wiring diagram (Fig.5).
USE AND MAINTENANCE
• It is recommended to operate the appliance prior to cooking.
It is recommended to leave the appliance in operation for 15 minutes
after cooking is terminated in order to completely eliminate cooking
vapours and odours.
The proper function of the cooker hood is conditioned by the regularity
of the maintenance operations, in particular,the grease filter.
• The anti-grease filters capture the grease particles suspended in the
air, and are therefore subject to clogging according to the frequency of
the use of the appliance.
In order to prevent fire hazard, it is recommendable to clean the filter
at least every 2 months by carrying out the following instructions:
- Remove the filters from the cooker hood and wash them in a solution
of water and neutral liquid detergent, leaving to soak.
- Rinse thoroughly with warm water and leave to dry.
- The filters may also be washed in the dishwasher.
The aluminium panels may alter in colour after several washes. This
is no valid reason to claim replacement of the panels.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR
EVENTUAL DAMAGES CAUSED BY BREACHING THE ABOVE
WARNINGS.
- 7 -
