Laser wavelength
Laser power
Battery type
Protection level
Dimensions
Weight
EXPLANATION OF USED SYMBOLS
1
1. Caution, laser radiation!
2. Caution, laser radiation – do not look in the laser beam
3. Read the instruction manual, observe warnings and safety conditions therein.
4. Segregated waste collection
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual:
1. Self levelling lock switch
2. Function change
3. Pulse button
4. Stand thread
5. Battery lid
* Differences may appear between the product and drawing

MEANING OF SYMBOLS

CAUTION
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Magnetic holder
2. Case
Battery replacement
• Carefully pull the lid latch in order to unlock the battery lid (5).
2 3
7
630–670 nm
< 1 mW
3 AA 1.5 V batteries
IP 54
92 x 84 x 50 mm
330 g
4
