Installing a DIMM

Step 1. Unlock a DIMM slot by pressing the retaining clips outward.
Step 2. Align a DIMM on the slot such that the notch on the DIMM
Step 3. Firmly insert the DIMM into the slot until the retaining clips at both
Downloaded from www.Manualslib.com
may be damaged.
5. If you adopt DDR3 2600/2400/2133/1866/1600 memory
modules on this motherboard, it is recommended to install
them on DDR3_A2 and DDR3_B2 slots.
Please make sure to disconnect the power supply before add-
ing or removing DIMMs or system components.
matches the break on the slot.
The DIMM only fits in one correct orientation. It will cause per-
manent damage to the motherboard and the DIMM if you force
the DIMM into the slot at incorrect orientation.
ends fully snap back in place and the DIMM is properly seated.
ASRock FM2A85X Extreme4-M Motherboard
manuals search engine
notch
break
notch
break
19
