Pushbuttons

3.

Device Configuration

For configuration of the device press "Set"-key (key 4) for 2 seconds, the first menu will be shown.
Choose between the individual values that can be set by pressing the "Set"-key (key 4) again.
The individual values are changed by pressing the keys
Use key "Store" (key 6) to leave configuration and to store settings.
3.1

‚Type': Selection of the Thermocouple-Type

3.2

‚Resolution': Selection of Display Resolution (Not for Type S!)

3.3 ‚Unit': Selection of Temperature Unit °C /°F
3.4

‚Corr': Selection of Display Correction Factor

3.5

‚Offset': Zero Displacement

Technical changes reserved
button 1:
button 4:
press (Menu) for 2 sec.:
button 2, 5: min/max when taking measurements:
press shortly:
press for 1 sec.:
up/down for configuration:
button 6:
Measurement:
Set/Menu:
button 3: no function
(key 2) or
▲
ni.cr: type K, NiCr-Ni
n:
type N, NiCrSi-NiSi
S:
type S, Pt10Rh-Pt
t:
type T, Cu-CuNi
J:
type J, Fe-CuNi
1°: Resolution 1°C
0.1°: Resolution 0.1°C
Auto: Resolution is selected automatically
Attention: When type S is selected the resolution is always 1°C!
°C: All temperature values in degrees Celsius
°F: All temperature values in degrees Fahrenheit
0.950...1.200: The temperature value (referring to 0°C or 32°F) will be multiplied by this factor.
Thus, in case of surface measurements, losses by transfer can be compensated
for (>1.000). Furthermore the factor can be used to compensate probe deviations.
off:
Factor deactivated (=1.000)
-10.0°C...10.0°C
or
-18.0°F...18.0°F:
off:
