T&S UK-0107 Installations- Und Wartungsanleitungen Seite 3

Spray Valve Assembly
1 Ring, Hold Down
2 * #27 Washer
3 Body, Spray Valve
4 Handle
5 Nut, Handle
6 Screw, Handle
7 Nipple
8 Cup, Spray
9 Ring, Sprayhead
10 * Sprayface
11 * Screw, Sprayface
Bonnet Assembly
12 Asm, Bonnet
13 * Stem
14 * Washer, Seat
15 * Washer, Bonnet Binding
16 Bonnet
17 * Washer, Bonnet Brass
18 * Quad Seal
19 * Spring, Bonnet
20 Pushbutton
21 Grease Pack (O-Ring Lubricant)
* Indicates parts Included in the UK-10K Parts Kit
Part Number Guide
3
000907-45
010476-45
000065-40
011454-45
003198-45
003199-45
000694-40
000019-40
011475-45
011456-45
000913-45
010594-40
009306-20
010563-45
010565-45
000608-25
000974-45
014615-45
000895-45
000753-25
010573-45
