5-6.Save Function
Press the SAVE Button (F3), into save menu.
Auto range
ENTER
UP
ENTER
UP
5-7.Storing Individual Measurement Data
• For common measurement functions, a snapshot of the screen data is saved by pressing
the SAVE Button (F3).
• Then pressing the DOWN Button (F3) to the save select item, pressing the
ENTER Button (F1).
5-8.Viewing Memory Data
• Viewing data stored in the Meter's memory is performed through the save menu.
• Press the DOWN Button (F3), position the menu selector next to the menu item labeled
ViewM, and pressing the ENTER Button (F1).
Auto range
06:32
DOWN
ENTER
UP
DO WN
CANCEL
22
06:32
DOWN
CANCEL
DO WN
CANCEL
EN
5-9.Viewing Graph Data
• Viewing data stored in the Meter's memory is performed through the save menu.
• Press the DOWN Button (F3), position the menu selector next to the menu item labeled
ViewG, and pressing the ENTER Button (F1).
• Press the << Button (F2) and the >> Button (F3) to move cursor.
5-10.Recording Measurement Data
• Press the SAVE Button (F3), then pressing the DOWN Button (F3) to the Record select
Item, pressing the ENTER Button (F1), Press the softkey labeled Start to start records.
• The recording session will continue until the allocated memory is used, the batteries
expire, the rotary switch is moved, or the session is terminated by pressing the CLOSE
Button (F4) labeled stop.
Auto range
ENTER
UP
06:32
Auto range
366. 55
Set Duration: 00Day
Set Duration: 00Days 00Hrs 01Mins
s 00Hrs 01Min
Set Sample Inter
Set Sample Interval: 00Min 01Sec
val: 00Min 01Sec
Start Record
Start R e cord
Battery: partly empty
Batter y: partly empty
DOWN
DO WN
CANCEL
ENTER
UP
EN
06:32
mV
DOWN
DO WN
CL OSE
23
