1. Identification data

Manufacturer Hoffmann Supply Chain GmbH
Franz-Hoffmann-Str. 3
90431 Nuremberg
Germany
Brand GARANT
products INFO Point, various versions
Computer desk, various versions
GridLine computer workstation, various
versions
Version of the operat- 02 Translation of the original instruction
ing instructions manual
Date created 04/2020
These brief instructions include all safety notes, de-
tails on commissioning and essential basic features.
Online instruction manual at ho7.eu/ba-computer-
place

2. General instructions

Read the instructions for use, follow them and keep them
available for later reference.

2.1. SYMBOLS AND MEANS OF REPRESENTATION

Warning symbol Meaning
Indicates a hazard which if not avoided will
DANGER
lead to death or serious injury.
Indicates a hazard which if not avoided may
WARNING
lead to death or serious injury.
Indicates a hazard which if not avoided may
CAUTION
lead to minor or moderate injury.
Indicates a hazard which if not avoided may
NOTICE
lead to damage to property.
i
Indicates useful tips and instructions together
with information for efficient and problem-
free operation.

2.2. FURTHER INFORMATION

Observe operating instructions for monitor, computer and other
peripheral devices.
3. Device sketch
i
Example illustrations.
3.1. INFO POINT
1
2
3
4
5
6
1 Sheet metal casing
2 Monitor housing for 24-
inch monitor
3 DOM cylinder lock
7
5 Cabinet compartment for
computer
6 Perforated back panel
7 Mobile unit with two castors
and two braked castors
www.hoffmann-group.com
4 Panel for keyboard and
mouse
3.2. COMPUTER DESK
1
6
5
2
3
4
1 Monitor bracket based on
VESA mount
2 Detachable storage shelf
3 Cable pass-through
4 Perforated back panel
3.3. COMPUTER WORKSTATION
1 Monitor housing
2 Cylinder lock
3 Cable pass-through
4 Panel for keyboard and
mouse
5 Cabinet shell fan
7
5 Laptop compartment
6 Cylinder lock
7 Mobile unit with two castors
and two braked castors
1
2
3
9
4
5
6
7
6 Shelf
7 Sheet-steel hinged door
8 Mobile unit with two fixed
wheels and two braked
castors
9 Push handle
en
3
8
