9 Faults

Warning:
- Disconnect the power supply before carrying out work on the unit.
- The electrical installation must be carried out by an electrical engineer with the
relevant training and qualifications.
Table 3, faults when connected to a IQ Manager
Signalling
LEDs on anti-static
bar do not light up
LEDs on anti-static
bar flashing green 1
Hz
LEDs on anti-static
bar light up red
LEDs on anti-static
bar light up orange
LEDs on anti-static
bar flashing red (1
Hz)
However, high
voltage to the
emitters.
LEDs on anti-static
bar flashing red (5
Hz)
PerformaxIQEasyPerformaxIQEasySpeed_UM_9752154110_NL_D_GB_V1_2
Problem
No high voltage on
the emitters
No high voltage on
the emitters
Anti-static bar
overload
No/poor ionisation,
but high voltage on
the emitters
High voltage not
maximum
No communication
with IQ Easy
platform
Cause
No supply voltage
Wiring fault
Bar is in standby mode
No Remote on/off signal
from Manager
Remote on/off source=
Remote input1
Anti-static bar is dirty
Anti-static bar mounted
too
close to conductive
machine parts.
Anti-static bar is dirty
Emitters are damaged
Anti-static bar positioned
incorrectly
Emitters are covered
Supply voltage too low
Internal temperature too
high
If connected to outputs 5
or 6: these are
configured for analog I/O
Wiring fault
Solution
Switch on Manager
Detect fault and repair,
see 5.6
Turn on the bar using
the Manager
Send remote on signal
on I/O connector of the
Manager or select
Remote on/off source =
continuous
Clean anti-static bar
Move anti-static bar
Clean anti-static bar
Replace the anti-static
bar
Reposition anti-static
bar, see section 5.2
Remove cover
Check 24 V DC
Manager or increase
diameter of connection
cable or shorten the
connection cable
Check for metal parts
close to the bar.
Select Serial mode in
the Backplane of the
Manager
Detect fault and repair,
see 5.6.1
