5.4 Mounting Performax IQ Easy, Performax IQ Easy Speed (slide bracket)

Figure 5: Fixing anti-static bar with mounting brackets
- Attach the mounting feet (1) to the machine. The triangles (2) have to point in the same
direction. Use appropriate M5 mounting material (3) for mounting.
- Slide the brackets (4) onto the anti-static bar.
Keep spacing(s) of the brackets (4) and mounting foot (1) equal and lock the bracket (2) with
the set screw (6).
- Set the anti-static bar with the brackets onto the mounting feet and slide the entire device in
the opposite direction of the three points.
- Lock the anti-static bar in the mounting feet by screwing the two adjusting screws (7) into the
brackets. With more than two brackets, only the two outer brackets need to be locked.
PerformaxIQEasyPerformaxIQEasySpeed_UM_9752154110_NL_D_GB_V1_2 60
