TECHNICAL DATA
Production code.......................................................................
..............................................................................................
..............................................................................................
..............................................................................................
Rated input ..............................................................................
Output ......................................................................................
No-load speed .........................................................................
Speed under load max. ...........................................................
Rate of percussion under load max. ........................................
Impact energy per stroke according to EPTA-Procedure 05/2009 ....
Impact energy per stroke (pre 2009) .......................................
Drilling capacity in concrete .....................................................
Tunnel bit in concrete, bricks and limestone ...........................
Core cutter in concrete, bricks and limestone .........................
Chuck neck diameter ...............................................................
Weight according EPTA-Procedure 01/2003 ...........................
Noise Information KH 5 E
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3 dB(A)) .......................................
Sound power level (K = 3 dB(A)) ............................................
Wear ear protectors!
Noise Information MH 5 E
Typically the A-weighted sound pressure level of the
tool is .......................................................................................
Measured values determined according to 2005/88/EG at the
user's ear.
2005/88/EC: Conformity assessment procedure according to
Annex VI. Notified Body:
VDE Testing and Certification Institute, Merianstr. 28,
63069 Offenbach, Germany
Measured sound power level ................................................
Guaranteed sound power level .............................................
Wear ear protectors!
Vibration Information
Total vibration values (vector sum in the three axes)
determined according to EN 60745.
:
Vibration emission value a
Hammer-drilling in concrete: vibration emission value a h
Uncertainty K = .......................................................................
Chiselling: vibration emission value a
....................................
Uncertainty K = ....................................................................... h
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Wear ear protectors. Exposure to noise can cause
hearing loss.
Use auxiliary handles supplied with the tool. Loss of
control can cause personal injury.
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting
accessory contacting a „live" wire may make exposed metal
18 ENGLISH
MH 5 E KH 5 E
..................... 4421 92 01... ............. 4421 79 01...
..................... 4421 87 01... ............. 4421 75 01...
..................... 4123 72 01... ............. 4123 57 01...
..................... 4123 62 01... ............. 4123 27 01...
...000001-999999 ...000001-999999
.......................1200 W .........................1200 W
.........................600 W ...........................600 W
............................... ..............................300 min
............................... ..............................300 min
.......................2840 min -1 .....................2840 min
..........................8,5 J ..............................8,5 J
...........................13 J ...............................13 J
............................... ................................40 mm
............................... ................................65 mm
............................... ................................90 mm
...........................66 mm ..........................66 mm
..........................6,2 kg ............................6,6 kg
............................... ................................99 dB (A)
............................... .............................. 110 dB (A)
...........................91 dB (A)
.........................101 dB (A)
.........................104 dB (A)
............................... ................................13 m/s
.......
h ............................... ...............................1,5 m/s
........................ 11,5 m/s ............................9 m/s
2
..........................1,9 m/s .........................1,9 m/s
2
parts of the power tool „live" and could give the operator an
electric shock.
Appliances used at many different locations including open
air should be connected via a residual current device of
30 mA or less.
Always wear goggles when using the machine. It is
recommended to wear gloves, sturdy non slipping shoes
and apron.
Sawdust and splinters must not be removed while the
machine is running.
Always disconnect the plug from the socket before carrying
out any work on the machine.
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine.
Always lead the cable away behind you.
When working in walls ceiling, or floor, take care to avoid
electric cables and gas or waterpipes.
The dust produced when using this tool may be harmful to
health. Do not inhale the dust. Wear a suitable dust
protection mask.
SPECIFIED CONDITIONS OF USE
KH 5 E: The pneumatic hammer can be universally used for
-1
hammer drilling and chiselling in stone and concrete.
-1
-1 MH 5 E:
The hammer can be used for chiselling in stone
and concrete.
Do not use this product in any other way as stated for
normal use.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that the product
described under "Technical Data" fulfills all the relevant
regulations and the directives 2011/65/EU (RoHs),
2006/42/EC, 2004/108/EC, 2005/88/EC (MH5E) and the
following harmonized standards have been used:
EN 60745-1:2009 + A11:2010
EN 60745-2-6:2010
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
EN 61000-3-2:2006 + A1:2009 + A2:2009
EN 61000-3-3:2008
Winnenden, 2013-04-03
Alexander Krug
Managing Director
Authorized to compile the technical file.
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
2
MAINS CONNECTION
2
Connect only to single-phase a.c. current and only to the
2
system voltage indicated on the rating plate. It is also
2
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.

MAINTENANCE

The ventilation slots of the machine must be kept clear at all
times.
Important note! If the carbon brushes are worn, in addition
to exchanging the brushes the tool should be sent to
after-sales service. This will ensure long service life and top
performance.
Use only AEG accessories and AEG spare parts. Should
components need to be replaced which have not been
described, please contact one of our AEG service agents
(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the machine type printed as well as the six-digit
No. on the label and order the drawing at your local service
agents or directly at: Techtronic Industries GmbH,
Max-Eyth-Straße 10, 71364 Winnenden, Germany.
Autogoods "130"
SYMBOLS
Please read the instructions carefully before
starting the machine.
Always disconnect the plug from the socket
before carrying out any work on the
machine.
Accessory - Not included in standard
equipment, available as an accessory.
Do not dispose of electric tools together
with household waste material! In
observance of European Directive 2002/96/
EC on waste electrical and electronic
equipment and its implementation in
accordance with national law, electric tools
that have reached the end of their life must
be collected separately and returned to an
environmentally compatible recycling
facility.
Class II construction, tool in which
protection against electric shock does not
rely on basic insulation only, but in which
additional safety precautions, such as
double insulation or reinforced insulation,
are provided.
