Dust Extraction; Operation / Settings; Preparation For Operation; Cutting Depth Adjustment - Graphite Pro 59Gp100 Betriebsanleitung

Upper guard
2.
Voltage indicator
3.
Lower guard lever
4.
Knob for base bevel adjustment
5.
Edge guide locking knob
6.
Cutting line indicator for 45°
7.
Cutting line indicator for 0°
8.
Base
9.
Cutting blade
10.
Flange washer
11.
Fixing bolt for cutting blade
12.
Lower guard
13.
Front handle
14.
Switch
15.
Switch lock button
16.
Main handle
17.
Cutting depth locking lever
18.
Spindle lock button
19.
Carbon brush cover
20.
Laser switch
21.
Laser
22.
Edge guide
23.
* Differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
Edge guide - 1 pce
1.
Hexagonal key - 1 pce
2.

PREPARATION FOR OPERATION

CUTTING DEPTH ADJUSTMENT

Cutting depth for right angle can be set from the range of 0 to 64
mm.
• Loosen the cutting depth locking lever (18).
• Set desired cutting depth (use the scale).
• Lock the cutting depth locking lever (18) (fig. A).
INSTALLATION OF THE EDGE GUIDE
Use the edge guide when cutting material to narrow pieces. Guide
can be installed on either left or right side of the power tool.
• Loosen the parallel guide locking knob (6).
• Insert the edge guide bar (23) into two holes in the saw base (9).
• Set desired distance (use the scale).
• Use the edge guide locking knob (6) to fix the edge guide (23)
(fig. B).
The edge guide (23) can also be used for bevel cutting at angles
ranging from 0° to 45°.
Never put hand or fingers behind the working saw. When kick
back happens the saw can fall on the hand, it may be the cause
of heavy body injury.
MOVING THE LOWER GUARD
Lower guard (13) of the cutting blade (10) is pushed away
automatically as the blade sinks into the material. To remove it
manually push the lower guard lever (4).

DUST EXTRACTION

Circular saw is equipped with dust extraction outlet (1) that allows
for extraction of sawdust produced when cutting.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the rating plate of
the saw. Hold the saw with both hands when starting up, because
engine torque may cause uncontrolled turn of the power tool.
Remember that rotating parts of the saw rotate for some time
after the tool has been switched off.
The saw is equipped with the switch lock button (16) that protects
against accidental start up.
Switching on:
• Press the switch lock button (16) (fig. C).
• Press the switch button (15).
Switching off:
• Release pressure on the switch button (15).
VOLTAGE INDICATOR
When the saw is connected to power supply socket, the voltage
indicator lamp (3) lights up.
LASER OPERATION
Never look directly at the source of the laser beam or its reflection
from reflective surface, never aim the laser beam at any person.
Laser beam allows for better control over the cut line.
The saw is equipped with the laser generator (22), which is used for
precise cutting. Always switch off the laser unit when the laser is not
used.
• Press the switch button (21) to on position.
• Laser starts to project red line, which is visible on the material.
• Make the cut along the line.
• Switch the laser off when cutting is finished.
Dust arising from cutting may suppress laser light, therefore it is
necessary to clean the generator lens occasionally.
CUTTING
Cutting line is defined by cutting line indicators (7) and (8).
• When starting operation always hold the saw firmly with both
hands by two handles.
• Switch on the circular saw only when it is away from the material
that is to be cut.
• Do not press the saw too hard. Pressure should be moderate and
continuous.
• After the cut is finished allow the cutting blade to stop completely.
• If the cutting is aborted before the task is completed, prior to
continuation start the saw and allow for idle operation. Wait until
the tool achieves its full rotational speed and then carefully drive
the cutting blade into the kerf in the processed material.
• When cutting perpendicular to fibres of material (wood), fibres
tend to lift up and tear off (moving the saw slowly minimizes this
effect).
• Ensure the lower guard reaches its extreme position.
• Before starting to cut always make sure that cutting depth locking
knob and knobs for base bevel adjustment are tightened firmly.
15
