SILENTRON VOCALPHONE BASIC Bedienungsanleitung Seite 18

POLARITY STOP MESSAGES 1 and 2: the input ter minals of the electric commands to obstruct the vocal messages are programmed to work
by closing the contact (NC line i n positi ve or negati ve independently). It is possible to programme the c ommand in NO modality: i n this cas e the
input ter minals mus t not always stay opened, as they would bl oc k the s ending of mess ages 1 and 2.
POLARITY SMS ST ART: the input terminals of the elec tric commands of the vocal messages and relati ve bloc ks are programmed to work by
opening the contact (NC line in negative). It is possible to programme in NO modality.
TIME/DATE: updating/modific ation of time and date.
SW ITCHBOARD: in case of a switchboard on the traditional phone line, enter a number (between 0 and 9) to acc ess the outsi de line: this will
avoid having to enter it before all numbers. In case of bidirectional working it should be avoided to pass through the switchbo ard;
connect on the dir ect line.
USER CODE – INSTALL ER CODE: options for c hange of the codes which have been set at s tart-up.
CANCELLATION OF PROGR AMMINGS: pay attention ! By pressi ng ↵ all programmings made will be er ased.
6) FURTHER FUNCTIONS OF VOCALPHONE (depending on the mod els)
6.1 TECHNICAL SMS (memor y-resident and not modifiable – only models with GSM module)
SMS 1: batter y of di aller discharged - at the s ame ti me the output C/BATT is clos ed to GND
SMS 2: abs enc e of mains or power suppl y
SMS 3: i nsufficient GSM covering for over 15 mi n. – at the same time the output GSM FIELD is clos ed to GND
SMS 4: none of the calls made on PSTN line was succ essful
SMS 5: periodical super vision c all
SMS 6: SIM expiry
6.2 TEST OF THE SYSTEM
For testing the s ystem the installer/user c ode has to be entered, and then followed by key ↑ . Digit the phone number on which to s end either the
voc al or the SMS mess age, then s elect either PSTN or GSM network; in default test condition voc al mess age 4 will be sent. In test condition the
speaker phone is enabled.
6.3 ACCESS TO HISTORIC AL FILE
Access to the historical file is obtained by entering the installer/user code, and then followed by key ↓ . The historical file lists date, ti me and
name of the c all + call-result (OK: success ful c all, KO: failed repl y, OC: bus y) of the l atest 50 calls, underlining possi ble lac k of GSM-field,
absence of PSTN line, changes occ urred from remote etc. Furthermor e ther e are indications regarding leaving ( ) or incoming ( ) calls, and
the type of call SMS (S) or vocal (V).
Either by pressi ng key ESC, or after a 1 mi n.-laps e the device will return to stand- by condition.
6.4 CHANGE OF PHONE NUMBERS FROM REMOTE
It will be possi ble to c hange the phone numbers stored in listing by means of a SMS from a remote GSM; the r emote phone has to be stor ed on
the s ys tem with direct access func tion "Y" (yes). Compos e a SMS as follows (bold):
A333555666 (old number to be replaced)
The device will memorize the c hange and will consequentl y s end a SMS stating: CHANGE *333666888* C ARRIED OUT.
6.5 AUTOMATIC PIN-MANAGEMENT
It is recommendable to always take away the PIN from the SIM-card; i n cas e this should not be possible the PIN has to be changed i nto 1234.
6.6 OPERAT IONS FROM REMOTE
Call on PSTN phone line - Note: the device r eplies only if the answering messag e no. 5 h as b een recorded: call the phone dialler and let
the phone ring from 1 to 3 ti mes, then hang up: in this way the device is able to answer the i ncoming calls automaticall y for 1 minute. Therefore
it is necessar y to call bac k within 1 mi nute, listen to the instruction message, enter USER CODE # (even during listening), and proceed with
the following possible c ommands :
digit 20 ∗ 1 # to switc h on the relay which is on board. Digit 21 ∗ 1 # to s witch on the el ectric output TC2.
-
digit 20 ∗ 0 # to switc h off the relay whic h is on board. Digit 21 ∗ 0 # to switc h-off the electric output TC2.
-
- digit 20 # to chec k the status of the relay which is on board (see remar ks). Digit 21 # to chec k TC2.
Call on GSM module: the s ame is al ways enabl ed to repl y to inc oming c alls: it is necess ary to listen to the instructi on message, to enter USER
CODE # even during listening (if the pers on who c alls has direct access it will not be necess ary to enter the user c ode), and to proceed with the
followi ng possibl e commands:
digit 20 ∗ 1 # to switc h on the relay whic h is on board. Digit 21 ∗ 1 # to switc h on the elec tric output TC2.
-
digit 20 ∗ 0 # to switc h off the relay whic h is on board. Digit 21 ∗ 0 # to switc h-off the electric output TC2.
-
- digit 20 # to chec k the status of the relay which is on board (see remar ks). Digit 21 # to chec k TC2.
REMARKS TO OPERAT IONS FROM REMOTE
The us er which is c alled from the device al ways has direct access to remote operation functi ons.
The correct receipt of the different digits is confirmed by the following ac oustic tones:
arming – s witc hing on = 3 tones (beep-beep-beep)
disarming – switc hing off = 1 tone (beep)
CALL OBSTRUCTION FROM REMOTE: when calls are r ecei ved from Voc alphone the c ycle of subsequent c alls may be i nterrupted by
pressing # on the phone whic h is called upon listening to the message and the BEEP of "message ended".
6.7 BACKLIGHTING OF THE DISPLAY
SILENTRON - ITALIA
A333666888 (new number to be stored).
