I-Tech MIO-CARE TENS Benutzerhandbuch Seite 68

1. PRG group selection
2. Selected program
3. CH1 intensity
4. Active channels
5. Low battery status
6. Next phase
7. CH2 intensity
8. Countdown timer
9. Device running
Program
Indicates the program chosen (2).
The rotor, changing every second, indicates that the device is
running (9).
Time
Indicates the amount of time left before the program ends (8).
Warns the user to increase the intensity by 1 or 2 units (using
the
Indicates which of the 2 channels is active: the left arrow
indicates that CH1 is active, the right arrow indicates that CH2
is active, both arrows together indicate that both CH1 and CH2
are active (4).
Indicates the intensity selected for channel 1 (3).
Indicates the intensity selected for channel 2 (7).
Indicates low battery (5).
IACER Srl
key) (6).
68 MNPG95-05
