Mounting and removing the sanding paper (Fig. B)
• Hold the machine on its side or upside down.
• Mount sanding paper (9) with the required grain
size onto the sanding pad (4). Make sure that the
perforation in the sanding paper (9) corresponds
with the perforation on the sanding pad (4).
• To remove the sanding paper (9), simply pull the
sanding paper from the sanding pad (4).
Note: Use coarse sanding paper for sanding rough,
uneven surfaces. Use medium sanding paper for
removing the remaining scratches from the coarse
sanding paper. Use fine sanding paper for finishing
surfaces.

4. OPERATION

Switching on and off (Fig. A)
• To switch on the machine, press the on/off
switch (1) into position I.
• To switch off the machine, press the on/off
switch (1) into position 0.
Setting the speed (Fig. A)
The speed adjustment wheel (3) is used for setting
the speed. The speed adjustment wheel can be
set to 6 positions. The ideal speed depends on the
required grain size and on the material to be worked.
Hints for optimum use
• Clamp the workpiece.
• Firmly hold the machine with both hands.
• Switch on the machine.
• Place the sanding pad with sanding paper on
the workpiece.
• Slowly move the machine over the workpiece,
firmly pressing the sanding pad against the
workpiece.
• Do not apply too much pressure on the machi-
ne. Let the machine do the work.
• Switch off the machine and wait for the ma-
chine to come to a complete standstill before
putting the machine down.

5. MAINTENANCE

Before cleaning and maintenance, always
switch off the machine and remove the
battery pack from the machine.
WWW.VONROC.COM
Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that the
ventilation openings are free of dust and dirt. Re-
move very persistent dirt using a soft cloth moiste-
ned with soapsuds. Do not use any solvents such
as gasoline, alcohol, ammonia, etc. Chemicals such
as these will damage the synthetic components.
ENVIRONMENT
Faulty and/or discarded electrical or
electronic apparatus have to be collected at
the appropriate recycling locations.
Only for EC countries
Do not dispose of power tools into domestic waste.
According to the European Guideline 2012/19/EC
for Waste Electrical and Electronic Equipment and its
implementation into national right, power tools that
are no longer usable must be collected separately
and disposed of in an environmentally friendly way.

WARRANTY

VONROC products are developed to the highest
quality standards and are guaranteed free of defects
in both materials and workmanship for the period
lawfully stipulated starting from the date of original
purchase. Should the product develop any failure
during this period due to defective material and/or
workmanship then contact VONROC directly.
The following circumstances are excluded from this
guarantee:
• Repairs and or alterations have been made
or attempted to the machine by unauthorized
service centers;
• Normal wear and tear;
• The tool has been abused, misused or
improperly maintained;
• Non-original spare parts have been used.
This constitutes the sole warranty made by compa-
ny either expressed or implied. There are no other
warranties expressed or implied which extend
beyond the face hereof, herein, including the im-
plied warranties of merchantability and fitness for
a particular purpose. In no event shall VONROC be
liable for any incidental or consequential damages.
The dealers remedies shall be limited to repair or
replacement of nonconforming units or parts.
EN
9
