Routing Cables

1 Open the wire cable basket on the top of the cable-management arm,
Figure 1-9. Routing Cables on the Cable-Management Arm
2 If applicable, connect the system status-indicator cable to its connector
3 Attach the I/O cable connectors and power cable connectors to their
4 Route the cables along the bend in the cable-management arm.
5 Adjust the cable slack as needed at the hinge position and secure
Downloaded from www.Manualslib.com
to enable cables to be routed within the arms (see Figure 1-9).
1 tie wraps (2)
3 cable-management arm
on the system back panel.
Route the system status-indicator cable through the cable-management
arm, and press the LED end into the slot on the end of the cable-
management arm until it snaps into place.
respective connectors on the system back panel.
For details on cable connections, see your system's Getting Started Guide
or Hardware Owner's Manual.
NOTE:
Use the retainer brackets on the back of the power supplies to provide
strain relief for the power cables.
the cables with the tie wraps (see Figure 1-9).
manuals search engine
4 3
2 system status-indicator cable connector
4 wire cable basket
Rack Installation Guide
1
2
21
