technical features

Technical data
Power supply
Electrical uptake
Operating temperature
Storage temperature
Dimensions
Bus wire length and cross-sectional area
NOTE:
IN ORDER TO AVOID INTERFERENCE PROBLEMS, USE A
SHIELDED CABLE OR TWISTED PAIR CABLE.
Insulation class
Protection rating
Temperature sensor
Product Technical Sheet
Supplier name
Manufacturer's model ID
Temperature control class
Energy efficiency contribution (%) for space heating
If an Atag external sensor is added:
Temperature control class
Energy efficiency contribution (%) for space heating
In a system with 3 zones with 1 ATAG Oz and 1 ATAG Cube:
Temperature control class
Energy efficiency contribution (%) for space heating
BUS 8 to 24V max / Limited Power Source
complies
6 mA
0 to 40°C
-10 to 70°C
93 x 88 x 24 mm
max. 50 m - min. 0,6 mm²
III
IP30 (when installed as specified)
±1%
ATAG
Cube
V
+3%
VI
+4%
VIII
+5%
