O P E R A T I N G I N S T R U C T I O N S
Television simulator "TV01"
Item no. 59 56 87
Intended use
The product is used to simulate the presence of persons and scare away burglars. The light of the integrated
coloured LEDs changes in colour and brightness through a random generator, and thus simulates the light
effects of a normal TV programme.
The function can be enabled automatically at dusk for 4 or 7 hours via a brightness sensor. You can also
switch the product on or off using a timer (available as accessory), as required.
Always observe the safety instructions and all other information included in these operating instructions.
Any use other than that described above could lead to damage to this product and involves the risk of short
circuits, fi re, electric shock, etc.
This product complies with the applicable national and European requirements. All names of companies and
products are the trademarks of the respective owners. All rights reserved.
Package content
• Television simulator
• Wall plug transformer
• Operating instructions
Explanation of the symbols
The lightning symbol in a triangle is a warning to inform you of potential risks of personal injury,
such as electric shock.
This symbol indicates specifi c risks associated with handling, function and use.
The "Hand" symbol indicates special tips and operating information.
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe these safety
instructions! We do not assume any liability for any resulting damage!
We shall not accept liability for damage to property or personal injury caused by incorrect
handling or non-compliance with the safety instructions! In such cases, the warranty will
be null and void.
• The unauthorised conversion and/or modifi cation of the product is not permitted for safety and
approval reasons (CE).
• The product is not a toy. Devices operated using mains voltage do not belong in the hands of
children. Therefore, be especially careful when children are around.
Use the product where it is out of the reach of children.
• The product is intended for use only in dry, indoor locations. No part of the product should
become damp or wet; never handle it if your hands are wet!
With the wall plug transformer there is also the deadly peril of an electric shock!
• Do not pull the wall plug transformer from the mains socket by pulling on the cable. Hold it on
the sides of the casing and then pull it out of the mains socket.
• If the wall plug transformer is damaged, do not touch it; there is danger to life from electric
shock!
Switch off the mains socket to which the wall plug transformer is connected (switch off at the
corresponding circuit breaker or remove the safety fuse, then switch off the earth leakage
circuit breaker). Unplug the wall plug transformer from the mains socket.
Replace the defective wall plug transformer only with a wall plug transformer of the same
design.
• The design of the wall plug transformer complies with Protection Class II. Only use a stand-
ard mains socket as the voltage source for the wall plug transformer (see section "Technical
Data").
The mains socket into which the wall plug transformer is plugged must be easily accessible.
• Caution, LED light:
Do not look directly into the LED light!
Do not look into the beam directly or with optical instruments!
• Do not leave packaging material carelessly lying around, since it could become a dangerous
plaything for children.
• Handle the product with care; it can be damaged by impacts, blows, or accidental falls, even
from a low height.
Getting Started
www.conrad.com
• Connect the round low voltage plug of the wall plug transformer provided to the corresponding socket on
the television simulator.
Version 07/13 • Plug the wall plug transformer into a standard mains socket.
• You can now select the function via the sliding switch on the back:
"OFF"
"+4"
"+7"
"ON"
• Place the television simulator on a level, stable surface so that it cannot fall down. Protect valuable furni-
ture surfaces from dents or scratch marks using a suitable underlay.
Maintenance and Care
• The product does not require any maintenance. You should never take it apart. The LED bulbs used are
permanently installed; they cannot be replaced.
• Before carrying out any cleaning, the product is to be separated from the mains voltage, pull the wall plug
transformer from the mains socket.
• The outside of the product should only be cleaned with a clean, soft, dry cloth. Do not use aggressive
cleaning agents or chemical solutions that could damage the housing (discolouring) or impair operation.
• Do not press too strongly on the front panel as this may cause scratches or other damage.
Disposal
Technical Data
a) Television simulator
Light bulb .....................................12 LEDs (7 x white, 2 x green, 2x blue, 1x red; not replaceable)
Power consumption .....................max. approx. 2 W
Dimensions ..................................85 x 75 x 57 mm (W x H x D)
Weight .........................................approx. 72 g
b) Wall plug transformer
Operating voltage ........................100 - 240 V/AC, 50/60 Hz
Output ..........................................9 V/DC, 1 A
The television simulator is switched off.
The television simulator is switched on at dusk for 4 hours; afterwards, it switches off automati-
cally.
When the ambient brightness falls below the switching threshold again on the next day, the
device is switched on again for 4 hours.
The function is as described above under "+4", however, the television simulator remains
switched on for 7 hours.
The television simulator is permanently switched on.
This switch position has to be used if you want to use the television simulator via an external
timer, for example. You can fi nd various suitable clock timers in our catalogues or online at
www.conrad.com.
This way, you can also activate the television simulator during the day or randomly control its
activation.
The mounting location should be a place that is not directly visible from outside. Otherwise, the
burglar may notice that this is not a real television set.
Check the light effects of the activated television simulator from outside your apartment, and if
required, choose a different mounting location.
Do not direct a lamp towards the television simulator, otherwise it may be switched on uninten-
tionally via the integrated twilight sensor (in the switch position "+4" or "+7"). Never cover the
television simulator.
Electrical and electronic devices must not be disposed of as domestic waste!
Please dispose of the product when it is no longer of use according to current statutory require-
ments.
These operating instructions are a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1,
D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfi lming,
or the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in
technology and equipment reserved.
© Copyright 2013 by Conrad Electronic SE.
